Configure collateral backing for DALP assets

Configure collateral ratios and issue collateral verifications via API. The collateral compliance module ensures assets are backed by verifiable reserves.

This guide explains how to configure the collateral compliance module and issue collateral claims via API, ensuring your tokenized assets are backed by verifiable reserves.

For the web interface approach, see the user guide.

How collateral validation works

When minting new units of an asset with the collateral module enabled, the system:

Checks if the asset's identity has a valid collateral claim
Verifies the claim was issued by an authorized issuer and is not expired
Confirms the collateral amount meets or exceeds the configured ratio based on post-mint total supply

This module only applies to minting operations. Regular transfers between wallets are not affected by collateral requirements.

Configuration parameters

When configuring the collateral module during asset creation, three parameters are required:

Parameter	Type	Description	Valid values
proofTopic	BigInt	ERC-735 claim topic ID for collateral proofs	System-provided topic ID
ratioBps	number	Required backing ratio in basis points (10000 = 100%)	0 to 20000
trustedIssuers	string[]	Additional trusted issuers for the proof topic	Ethereum addresses

Understanding collateral ratios

The collateral ratio is specified in basis points (1/100th of a percent): - 10000 = 100% backing (1,000 minted units require 1,000 collateral) - 15000 = 150% over-collateralized (1,000 minted units require 1,500 collateral) - 20000 = 200% maximum ratio (1,000 minted units require 2,000 collateral)

See Example scenario for a minting simulation.

Configure collateral during asset creation

Prerequisites

Platform URL (e.g., https://your-platform.example.com)
API key from a user with the Token Manager role (see Getting Started for API key setup)
Wallet verification method enabled on your account (e.g., pincode or 2FA)

Supply cap and collateral requirement configuration

Get collateral module address

Query the system to get the registered collateral compliance module address:

curl -X GET "https://your-platform.example.com/api/system/default" \
  -H "X-Api-Key: YOUR_API_KEY"

Response:

{
  "complianceModuleRegistry": {
    "complianceModules": [
      {
        "typeId": "collateral",
        "module": "0x5FC8d32690cc91D4c39d9d3abcBD16989F875707",
        "name": "Collateral Compliance Module"
      }
      // ... other modules
    ]
  }
}

Save the module address for the typeId: "collateral" entry.

Get collateral topic ID

Query the registered claim topics to find the collateral topic ID:

curl -X GET "https://your-platform.example.com/api/system/claim-topics" \
  -H "X-Api-Key: YOUR_API_KEY"

Response:

[
  {
    "id": "0x534b8f03c16c92c70d1da1d2fae43b98352bf3d7...",
    "topicId": "56591694316807385155654796962642700009023257328234168678289712861780104020528",
    "name": "collateral",
    "signature": "uint256 amount, uint256 expiryTimestamp",
    "registry": {
      "id": "0x534b8f03c16c92c70d1da1d2fae43b98352bf3d7"
    }
  }
  // ... other topics
]

Save the topicId value for the topic with name: "collateral".

Create asset with collateral module

Include the collateral module in the initialModulePairs array when creating the asset:

curl -X POST "https://your-platform.example.com/api/token/create" \
  -H "X-Api-Key: YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "type": "equity",
    "name": "Collateralized Equity",
    "symbol": "COLEQ",
    "decimals": 18,
    "countryCode": "840",
    "priceCurrency": "USD",
    "basePrice": "100",
    "initialModulePairs": [
      {
        "typeId": "collateral",
        "module": "0x5FC8d32690cc91D4c39d9d3abcBD16989F875707",
        "values": {
          "proofTopic": "56591694316807385155654796962642700009023257328234168678289712861780104020528",
          "ratioBps": 10000,
          "trustedIssuers": []
        }
      }
    ],
    "walletVerification": {
      "secretVerificationCode": "YOUR_PINCODE",
      "verificationType": "PINCODE"
    }
  }'

Response:

{
  "id": "0x1234567890AbCdEf1234567890AbCdEf12345678",
  "txHash": "0x8d95bfd5381478d90992d3e2e64c73178e46bb18592bfcbffdf899f2407aee9b"
}

Key fields in initialModulePairs:

Field	Description
`typeId`	Must be `"collateral"` for the collateral module
`module`	The collateral module address from step 1
`values.proofTopic`	The collateral topic ID from step 2
`values.ratioBps`	Collateral ratio (10000 = 100%, 15000 = 150%)
`values.trustedIssuers`	Additional issuers recognized alongside the global registry (not a replacement)

Verify module configuration

Query the asset to confirm the collateral module is configured:

curl -X GET "https://your-platform.example.com/api/token/0x1234567890AbCdEf1234567890AbCdEf12345678" \
  -H "X-Api-Key: YOUR_API_KEY"

Check that complianceModuleConfigs contains an entry with typeId: "collateral".

Issue a collateral claim

After the asset is deployed with the collateral module, a collateral claim must be issued to the asset's identity before minting can occur.

Prerequisites

Collateral claims must be issued by a Trusted issuer for the collateral topic (see Configure trusted issuers)

Who should issue collateral claims?

Most teams delegate collateral attestations to compliance or treasury officers who operate as trusted issuers. Assign the claimIssuer role to those identities and register them for the collateral topic so they can service multiple assets.

Claim fields

Field	Description	Format
amount	The collateral value backing the asset	String (in base units)
expiryTimestamp	When the claim expires (must be in the future)	ISO 8601 date-time

Issue the collateral claim

The collateral amount must be specified in base units (the smallest unit of the asset). For an asset with 18 decimals, multiply the desired amount by 10^18. For example, to back 100,000 units on an 18-decimal asset, use "100000000000000000000000" (100,000 × 10^18).

You issue collateral claims to the token's OnchainID identity using the system endpoint. You can obtain the targetIdentityAddress from the token creation response (identity.id) or by calling GET /token/{address}.

Use the identity contract address

Collateral claims are issued to the token's identity contract, not the token address or an operator wallet. Always pass the identity.id value as targetIdentityAddress.

curl -X POST "https://your-platform.example.com/api/system/identity/claim/issue" \
  -H "X-Api-Key: YOUR_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "targetIdentityAddress": "0x20ADDd5023c494eA1594282ab6E94fA5A658C4f2",
    "claim": {
      "topic": "collateral",
      "data": {
        "amount": "100000000000000000000000",
        "expiryTimestamp": "2025-12-31T23:59:59Z"
      }
    },
    "walletVerification": {
      "secretVerificationCode": "YOUR_PINCODE",
      "verificationType": "PINCODE"
    }
  }'

Response:

{
  "txHash": "0x9f85bfd5381478d90992d3e2e64c73178e46bb18592bfcbffdf899f2407aee9b",
  "success": true,
  "claimTopic": "collateral",
  "targetIdentity": "0x20ADDd5023c494eA1594282ab6E94fA5A658C4f2"
}

Amount formatting

Asset amounts depend on the asset's decimal configuration. See Asset Decimals for formatting guidance.

With this collateral claim of 100,000 units and the 100% ratio configured above, you can mint up to 100,000 tokens. See Example scenario for a detailed minting simulation.

Verify the claim

Query the asset to confirm the collateral claim was issued:

curl -X GET "https://your-platform.example.com/api/token/0x1234567890AbCdEf1234567890AbCdEf12345678" \
  -H "X-Api-Key: YOUR_API_KEY"

Response (relevant fields):

{
  "id": "0x1234567890AbCdEf1234567890AbCdEf12345678",
  "type": "equity",
  "name": "Collateralized Equity",
  "symbol": "COLEQ",
  "identity": {
    "id": "0x20ADDd5023c494eA1594282ab6E94fA5A658C4f2",
    "claims": [
      {
        "name": "collateral",
        "revoked": false,
        "values": [
          { "key": "amount", "value": "100000000000000000000000" },
          { "key": "expiryTimestamp", "value": "1767225599" }
        ],
        "isTrusted": false
      }
    ]
  },
  "complianceModuleConfigs": [
    {
      "complianceModule": {
        "typeId": "collateral"
      }
    }
  ]
}

Key fields to verify:

identity.claims contains the collateral claim with amount and expiry
identity.claims[].revoked is false (claim is active)

Plan for renewal

Collateral claims have an expiry date. Renew claims before they expire to avoid blocking future minting operations.

Example scenario

Using the configuration from this guide, a company issues equity shares with 100% collateral backing.

Configuration

Collateral ratio: 100% (10000 basis points)
Proof topic: System default (collateral)
Trusted issuers: Empty (using global registry)

Collateral claim

Amount: 100,000 units
Expiry: December 31, 2025

Minting simulation

Operation	Current supply	Mint amount	Post-mint supply	Required collateral (100%)	Available	Result
Initial mint	0	50,000	50,000	50,000	100,000	✅ Allowed
Second mint	50,000	50,000	100,000	100,000	100,000	✅ Allowed
Third mint	100,000	10,000	110,000	110,000	100,000	❌ Blocked

Why the third mint fails

The third mint is blocked because:

Post-mint supply would be 110,000 units
At 100% ratio, required collateral = 110,000
Current collateral claim only covers 100,000
A new collateral claim with a higher amount is needed

To unblock

Issue a new collateral claim with amount ≥ 110,000 (see Issue a collateral claim)
Retry the minting operation

Request parameters

Collateral module configuration

Parameter	Type	Required	Description
`typeId`	string	Yes	Must be `"collateral"`
`module`	string	Yes	Collateral module contract address (from system query)
`values.proofTopic`	string	Yes	ERC-735 claim topic ID (from claim topics query)
`values.ratioBps`	number	Yes	Collateral ratio in basis points (0-20000)
`values.trustedIssuers`	string[]	No	Additional issuers recognized alongside the global registry (not a replacement)

Collateral claim issuance

Parameter	Type	Required	Description
`targetIdentityAddress`	string	Yes	Token identity address receiving the claim
`claim.topic`	string	Yes	Must be `"collateral"`
`claim.data.amount`	string	Yes	Collateral amount as string (in base units)
`claim.data.expiryTimestamp`	string	Yes	Claim expiry in ISO 8601 format (must be in the future)
`walletVerification`	object	Yes	Wallet verification (pincode or TOTP)

Wallet verification object

Field	Type	Description
`secretVerificationCode`	string	6-digit pincode or TOTP code
`verificationType`	string	`"PINCODE"` (default), `"SECRET_CODES"`, or `"OTP"`

Best practices

Collateral ratio planning

Start with 100% (10000 basis points) for standard backing requirements
Use 150% (15000 basis points) or higher for over-collateralization when extra security is needed
Consider market volatility when setting ratios for assets backed by volatile collateral

Claim renewal

To renew a collateral claim, issue a new claim using the steps in Issue a collateral claim with an updated expiryTimestamp set to a future date.

Monitor collateral claim expiry dates and renew before they expire
Set calendar reminders or automated alerts for upcoming expirations
Allow buffer time for renewal to avoid blocking minting operations

Trusted issuers

Leave trustedIssuers empty to rely solely on the global registry
Adding addresses to trustedIssuers extends the global registry—it does not replace it
Use this array for issuers not registered globally but authorized for this specific asset
Verify issuer addresses carefully before adding them

Troubleshooting

Issue	Solution
`401 Unauthorized`	API key is invalid, expired, or disabled
`403 USER_NOT_AUTHORIZED`	Ensure the caller has the required role: `tokenManager` for asset creation, or `claimIssuer` and trusted issuer status for claim issuance
`Collateral module not found`	Query `/system/default` to get the correct module address
`Invalid topic ID`	Query `/system/claim-topics` to get the correct collateral topic ID
`Insufficient collateral`	Issue a collateral claim with sufficient amount before minting
`Collateral verification expired`	Issue a new collateral claim with a future expiry date
`ratioBps out of range`	Value must be between 0 and 20000

Configure Trusted Issuers - Set up issuer permissions
Mint Assets - Mint tokens after configuring collateral
